Genesis Straight Edge Aluminium Formable Tile Trim

2.5 Metre Length - Milled Aluminium Finish

SKU
EFACON
From £7.32 £6.10

Genesis Straight Edge Aluminium Formable Tile Trim is versatile trim option that can be used to protect corners and edges in rounded shaped areas due to it's flexible design. This means the tile trim can be shaped and formed to fit archways, circular or curved floor areas. These unique profiles are manufactured from top quality aluminium and have been specifically designed to protect corners and edges and are perfect for all types of wall and floor installations, porcelain tiles, ceramic tiles and other materials of varying depths.

Available in 2.5 Metres in length and milled aluminium finish as standard.

Genesis formable tile beading trims are available in various depth options which makes it ideal to find the right trim to fit your installation.

When choosing the depth of your Genesis Straight Edge Aluminium Formable Tile Trim we recommend allowing an extra 2mm of depth for the bed of adhesive beneath the tile being applied e.g. a 10mm deep tile trim would ideally be fitted with an 8mm deep tile, with a 2mm bed of adhesive beneath it.

Genesis aluminium formable tile trims create a stylish aesthetical finish as well as an effective protective edge when installed with all types of floor tiles, wall tiles and base substrates.

Genesis formable tile trims are supplied with a transparent protective film offering added protection during transport, storage and installation.

We also Supply certain trims in bespoke powder coated finishes to any RAL number on request.

Main Features:

  • Industry recognised brand
  • Robust Aluminium
  • Flexible / Formable
  • L Shape Profile
  • Perfect for curves, archways and round edges
  • Segmented Base Flanges For superior Adhesion
  • 2.5 Metre Length
  • Hard wearing surface
  • Milled Aluminium Finish
  • 6 Trim Depth Options
  • Protects Tile Edges
  • Custom RAL Finish Option Available

Available Trim Depth Sizes:

  • 6mm Depth (Recommended for 4mm depth tiles)
  • 8mm Depth (Recommended for 6mm depth tiles)
  • 10mm Depth (Recommended for 8mm depth tiles)
  • 12mm Depth (Recommended for 10mm depth tiles)
  • 15mm Depth (Recommended for 13mm depth tiles)
  • 18mm Depth (Recommended for 16mm depth tiles)

Suitable For:

  • Floors & Walls
  • Dividing Tiles
  • Edge Protection
  • Feature Border Trim
  • Vertical Feature Trim
  • Horizontal Feature Trim
  • Rounded edges

Key Areas of Use:

  • Internal Living Areas
  • Bathroom
  • Kitchen
  • Hallway
  • Lounge
  • Dining Areas
  • Conservatories
  • Curved Areas
  • Archways

Trim Material Anodised Aluminium
Available Trim Depths 6mm, 8mm, 10mm, 12mm, 15mm, 18mm
Trim Length 2.5 Metre
Width 23mm
Finish Milled Aluminium
Handling & Storage Stored and handled from original packaging, Protective film
Suitable Tile Depth Information Tile Depth + upto 2mm Adhesive = Trim Depth
Weight 0.3kg
Accreditations Aluminium AA 6063 T6 / UNS A96063 anodised to DIN 17611

How do I fit Genesis Straight Edge Aluminium Formable Tile Trim ?

To fit Genesis tiling trims, ensure that the base of the tile being applied is positioned onto the widest part of the trim which has perforated sections to allow for tile adhesive to pass through. Position the flat inside edge of the tile trim against the side of the tile and the thinnest top edge should be flush with the front face of the tile.

trimtraders-straight-edge-aluminium-tile-trim-installed

How do you cut Genesis Straight Edge Aluminium Formable Tile Trim ?

We recommend using a Genesis Mitre block tool and a Genesis hand saw with these tile trims to acheive an accurate clean cut. you can find more information about Genesis mitre blocks and Genesis cutting tools in the related products section on the left of the page.

What products do I use to clean my tile trim ?

No specific cleaning products are required to maintain and clean your metal tile edging trim. We simply recommend using a soft cloth or duster and a everyday cleaning product like polish to remove any smears, stains or finger prints.

How do I know which tile trim size will fit my tiles?

To work out the required tile trim depth to fit your tiles we recommend the following. First measure the depth of your tile in mm and then add an extra 2mm onto this measurement to allow for your tile adhesive. This calculation will provide you with the correct trim depth for your tiles. e.g. 8mm tile depth + 2mm adhesive = 10mm deep tile trim.

How do I work out how many lengths of trim I will need ?

The easiest way to work out how many tiling trim lengths you will need is to measuring the length and height of the tiled area with a tape measure and add these measurements together. This calculation should give you the overall amount of tile trim required in linear metres. Our trims are usually supplied in either 2.5 Metre or 2.7 Metre lengths offering better coverage for large tiled areas.
